3014 White

Category

Product Center

SMD LED

Product description: 3014 SMD LED Chip Product model: HLX-3014 Luminous color: white light Working power: 0.5W Colloidal color: Water clear and transparent Product size: 30*14MM Product material: Iron silver plating, gold wire, environmentally friendly and high temperature resistant glue products Certification: ISO9001:2015, SGS Product application: indoor and outdoor lighting, lighting decoration
Contact
Messages

Product Details

led chip 30143014 SMD LED Chip

Product number 3014JGC glow color White
Working current 150MA Operating Voltage 2.8-3.6V
Outline description SMD3014 colloid color transparent
Luminous brightness   Product Band Color Temperature 3000-3200K
5300-5600K
Beam angle 120° reverse voltage 5V
power 0.5W、1W　0.2W Product Size 30*14*18MM
Color rendering index Ra 96 Chip brand San'an
Bracket material silver plated iron Packaging material Silica gel
Conductive material Gold Line Luminous flux 22-24LM
ESD static electricity 2000V Soldering temperature 260°
Operating temperature -25-85° Certification ISO9001,SGS

Key words:

3014　SMDｌｅｄ

３０１４　ＬＥＤ　

３０１４SMD 0.5W white ligh

led chip 3014

Other products

4mm round head green hair green high 8MM

系列产品包含：

Product description: 4mm Round Head Transparent Dip Led Diode Product model: HLX-404YGD1B-8.0 Luminous color: yellow green light Colloid color: green fog Product size: Φ 4*H8.0MM Product material: silver plated iron, gold wire, environment-friendly high temperature resistant glue Product certification: ISO9001:2015, SGS Product application: electrical indicator bead

4mm round head green hair green high 8MM

5730 SMD 0.5W white smd chips

系列产品包含：

Product description: 5730 smd led chips Product model: HLX-5730BWC Luminous color: white light Working power: 0.5W Colloid color: clear and transparent Product size: 5.7 * 3.0MM Product material: silver plated iron, gold wire, environment-friendly high temperature resistant glue Product certification: ISO9001:2015, SGS Product application: LED strip lights, panel lights, LED bulbs, downlights, advertising light boxes, and automotive lighting

5730 SMD 0.5W white smd chips

5050 RGB 0.5W SMD LED

系列产品包含：

Product description: patch 5050 full-color RGB 0.5W Product model: HLX-5050RGB Luminous color: red, green and blue Colloid color: transparent Product size: 5 * 5.5 * 1.6MM Product material: silver plated iron, gold wire, environment-friendly high temperature resistant silica gel Product certification: ISO9001:2015, SGS Product application: fill light, color atmosphere light

5050 RGB 0.5W SMD LED

5mm LED - Blue 470nm 30 Degree Viewing Angle

系列产品包含：

Product size: Φ 5*H8.7MMProduct description: 5MM round head light Product model: HLX-504SBC1B Luminous color: blue light The Cool-White 5mm LED (T-1 ¾ through-hole) is extremely bright at 690mcd; its typical forward voltage is 3.6Vdc and drive current is 20mA, with a maximum forward current of 30mA. The lens is frosted, 5mm in diameter and projects light at a half angle of 70°. The bi-pin legs are the positive and negative leads of the LED; the longer of the two leads is the positive side (Anode). There is also a flat side on the base of the LED, this represent the negative side (Ca

5mm LED - Blue 470nm 30 Degree Viewing Angle
